For Yazaki Contacts
Product Introduction
Item No. :J12JY3 Quick Change Crimping Jaw for Yazaki YES/YESC 2.8 Unsealed Terminal -AWG 16/14
Suitable for
● DIN 1.5/2.5 mm2
Confined crimp For B Crimp(F Crimp) .The jaw structure is precise to ensure firmly grasps the wires after crimping.
Applicable: AUTO
For Yazaki YES/YESC 2.8 Unsealed Terminal
The J12JY3 Quick Change Crimping Jaw is engineered for Yazaki YES/YESC 2.8 unsealed terminals, supporting DIN 1.5 and 2.5 mm² (AWG 16/14) conductors. Its confined B Crimp (F Crimp) cavity ensures a strong and consistent grip, delivering reliable, deformation-free crimps for automotive wiring applications.
Compatible with all LiCrim Quick Change crimper handles—including JD, JB, JE, JC, and JFP series—this tool-free jaw system allows quick 5-second swaps with a simple slide-in/slide-out mechanism.
Compatible with LiCrim Quick Change crimper frames system as below:
- 9 plus Quick Change Ratchet Crimper JD series (Tools Only or With Contacts )
- 8.7" Quick Change Ratchet Crimper JB series (Tools Only or With Contacts )
- 10" Quick Change Ratchet Crimper JE series (Tools Only or With Contacts )
- 8.7" Light Quick Change Ratchet Crimper JC series (Tools Only or With Contacts )
- 9" Professional Parallel Ratchet Crimper / Item No.: JFP
Made in TAIWAN-More LiCrim Crimper Single Function : Please Press the button "Download" to get it.
Material: AISI- 4140
Procedure: Precision and Wax-lost Casting
Treatment: Finished with heat treatment
Surface treatment : Zinc Phosphate
AISI 4140 is a chromium-molybdenum alloy steel. The chromium content provides good hardness penetration, and the molybdenum content ensures uniform hardness and high strength. The jaws are heat treated and have a zinc phosphate surface treatment.
Designed in Germany. Made in Taiwan. Patented in the USA, Germany, China, and Taiwan.
Packing List: 120/240/CTN/14.9/15.9/KGS/1.2'
Sliding Card
Sliding Card Size: 11.3 x 8.3 x 1.5 cm
